IP Rating

IP50

Accepts Fiber Termination Type

T5 Termination

Power

DC

Cable Length (m)

2

NEMA / UL Type Rating

NEMA 4X

Housing Style

DIN Rail

Primary Housing Material

Thermoplastic

Input Output

Analog & Discrete

Color LED - Amplifiers

Long Infrared (Water Detection)

Fiber Type

Glass Only

Output

PNP

Connection

Cable

Output Type (Specific)

Analog & Discrete

Repeatability (µs)

100 to 180

Number of Pins

5

Max Op. Temperature (°C)

55

Min Op. Temperature (°C)

-10

Max Op. Relative Humidity (%)

90% @ 60°C

Special Feature: Remote Teach

Yes

Crosstalk Avoidance

Yes

Intrinsically Safe

No

Adjustments

Teach Button

Power Supply/Supply Voltage

12-30 V dc

Delay at Power-up (ms)

500

Indicator Display Type

Dual Digital Displays

Minimum response time (ms)

.5

Special Feature: Bussable Power

No

Analog Output

0 to 10 V dc

Feature: Timing (Hold/Delay)

Yes

Feature: Audible

No

Housing Material

Thermoplastic
