IP Rating

IP67

NEMA / UL Type Rating

NEMA 4X

Power

DC

Sensing Beam

Visible Red LED

Cable Length (m)

0.15

Supply Voltage

10-30 V dc

Sensing Mode (General)

Proximity

Sensing Mode (Detailed)

Background Suppression (Adjustable)

Housing Style

Rectangular

Primary Housing Material

ABS

Input Output

Discrete

Max Sensing Distance (mm)

300

Outputs

NPN

Power Supply/Supply Voltage

10-30 V dc

Connection

Pigtail QD

Quick Disconnect Type

M8

Operation

Light/Dark Operate

Min Op. Temp. (°C)

-20

Max Op. Temp. (°C)

55

Output response time (ms)

2.5

Sensing Beam Wavelength

640

Delay at Power-up (ms)

200

Repeatability (µs)

250

Number of Pins

4

Max Op. Relative Humidity [%]

95% @ 50°C

Lens Material

Acrylic

Adjustments

Mechanical Screw

Indicator

LEDs

Feature: Audible

No

Feature: Quick Disconnect

Yes

EPLAN Original Sent Date

06/06/2024

EPLAN Status

Published
