IP Rating

IP67

NEMA / UL Type Rating

NEMA 4X

Power

DC

Sensing Beam

Visible Red or IR

Cable Length (m)

9

Supply Voltage

10-30 V dc

Sensing Mode (General)

Opposed

Sensing Mode (Detailed)

Receiver

Housing Style

Rectangular w/M18 Mount

Primary Housing Material

ABS

Input Output

Discrete

Max Sensing Distance (mm)

20000

Outputs

PNP

Power Supply/Supply Voltage

10-30 V dc

Connection

Cable

Operation

Light/Dark Operate

Min Op. Temp. (°C)

-20

Max Op. Temp. (°C)

70

Output response time (ms)

0.75 ON/0.375 OFF

Delay at Power-up (ms)

100

Repeatability (µs)

100

Number of Pins

4

Max Op. Relative Humidity [%]

95% @ 50°C

Lens Material

Acrylic

Adjustments

N/A

Barrel Diameter (mm)

18

Indicator

LEDs

Opposed Mode Emitter/Receiver

Receiver

Feature: Audible

No

EPLAN Original Sent Date

01/29/2024

EPLAN Status

Published
